Connection to Database with Drizzle ORM in Node.js

___________________________________________

What’s

Today we’ll build a data courier system. The goal is to connect our application code to a database so we can seamlessly send and retrieve data using the Drizzle ORM.

_____________________________________________________________________________________________________

Let’s Try With Me!!

_____________________________________________________________________________________________________

Setup

___________________________________________________________________________________________

Technology

• Node JS

• Drizzle ORM

• Supabase

___________________________________________________________________________________________

Structure File

project/

|— index.js

|— schema.js

|— seed.js

|— .env

___________________________________________________________________________________________

Create Database

• Login in Supabase

• Create project

___________________________________________________________________________________________

Init & Install Project

• NPM Init

npm init -y

• Install Drizzle ORM

npm install drizzle-orm pg
npm install -D drizzle-kit

• Install .env

npm install dotenv

• Update file package.json, add this code in file package.json

"type": "method",

_____________________________________________________________________________________________________

Code Code!!

_____________________________________________________________________________________________________

Connect to Database

___________________________________________________________________________________________

Supabase

• Click connect

• Click and Click, then choose Transaction Pooler and copy url

• and paste in file .env and write your password account in supabase

___________________________________________________________________________________________

Code Index.js

import { drizzle } from 'drizzle-orm/node-postgres';
import { Pool } from 'pg';
import * as schema from './schema.js'

const pool = new Pool({
    connectionString: process.env.DATABASE_URL,
    ssl: { rejectUnauthorized: false }
})

export const db = drizzle(pool, { schema })

___________________________________________________________________________________________

Create file Drizzle

Create File drizzle.config.js

import 'dotenv/config'

export default {
    dialect: 'postgresql',
    schema: './schema.js',
    out: './drizzle',
    dbCredentials: {
        url: process.env.DATABASE_URL,
        ssl: { rejectUnauthorized: false }
    }
}

_____________________________________________________________________________________________________

Schema Database

___________________________________________________________________________________________

Code Schema.js

import { pgTable, serial, varchar, text, integer, timestamp, numeric } from 'drizzle-orm/pg-core';

export const note = pgTable('latihan_catatan', {
    id: serial('id').primaryKey(),
    note: varchar('note', { length: 256 }).notNull()
})

___________________________________________________________________________________________

Update File ‘package.json‘ in ‘scripts‘

"scripts": {
  "db:generate": "drizzle-kit generate",
  "db:migrate": "drizzle-kit migrate"
},

___________________________________________________________________________________________

Run Code

• open your terminal with ctrl + ` or click like this and choose terminal

• Write npm run db:generate then npm run db:migrate in terminal

_____________________________________________________________________________________________________

Seed Data

___________________________________________________________________________________________

Code Seed.js

import 'dotenv/config';
import { db } from './index.js';
import { note } from './schema.js';

async function seed() {
    console.log('Sedding database......')
    await db.delete(note)

    const note1 = await db.insert(note).values({
        note: "First step"
    })
    .returning();

    console.log(note1);
    console.log('✅ Sedding completed!')
    process.exit(0)
}

seed().catch((err) => {
    console.error('❌ Sedding failed:', err);
    process.exit(1)
})

___________________________________________________________________________________________

Update File ‘package.json‘ in ‘scripts‘

"scripts": {
    "db:seed": "node seed.js"
  }

• Run code with write npm run db:seed in terminal

_____________________________________________________________________________________________________

See Result

___________________________________________________________________________________________

_____________________________________________________________________________________________________

Update Column

___________________________________________________________________________________________

Update Code Schema.js

export const note = pgTable('latihan_catatan', {
    id: serial('id').primaryKey(),
    name: varchar('name', { length: 256 }).default('Anonymous').notNull(),
    note: varchar('note', { length: 256 }).notNull()
})

___________________________________________________________________________________________

Run Code

___________________________________________________________________________________________

Update Code Seed.js

const note1 = await db.insert(note).values({
        name: "The Champion",
        note: "We Are Champion"
    })
    .returning();

___________________________________________________________________________________________

Run Code

_____________________________________________________________________________________________________

See Result

___________________________________________________________________________________________

• This is result, we can add data to database

_____________________________________________________________________________________________________

Repository

• Github: https://github.com/MC-AHN/connection_to_database

_____________________________________________________________________________________________________

Closing

_____________________________________________________________________________________________________

Congratulations! You’ve just successfully built a solid data pipeline. Your application is no longer just isolated code—it can now seamlessly communicate with a PostgreSQL database.

From this project, we’ve learned how to:

• Build the Bridge: Connect Node.js to a database using the lightweight and fast Drizzle ORM.

• Design the Blueprint: Create and update table structures (schemas) with ease.

• Test with Confidence: Use Seeding to automatically fill your database with sample data for quick testing.

By skipping SSL, we've kept our setup simple and perfect for learning or local development. As you move forward, you can explore more complex data relationships or even add security layers when you're ready to take your project to the next level.

Happy coding and keep building! 🚀
